FEATURES
-40W Patented Gravity Projector Optics (GPO)
-DOT Compliant High/Low Beams with Day Running Light Support (Transport Canada (TC) Compliant for 07-18 Jeep JK with DRL equipped and enabled)
-Hard Coated Polycarbonate Lens
-Precision Die-Cast Aluminum Housing
-Plug-n-Play for 07-18 Jeep Wrangler JK/JKU With Factory Halogen Headlights
NOTE:
Does not fit 17-18 Jeep Wrangler JK Rubicon/Sahara editions or Jeeps equipped with factory LED headlights.
Lens depth will not fit in certain aftermarket grilles, such as the Angry Eye
LIGHT PERFORMANCE
- Raw Lumens: Low- 2,967 lm, High- 2,575 lm, DRL- 386 lm
- Lux @ 10 Meters: Low- 400 lx, High- 700 lx
- Candela: Low- 40,000 cd, High- 70,000 cd
- Beam Distance: Low- 400m, High- 529m
SPECIFICATIONS
- Wattage: Low- 20W, High- 30W, DRL- 1.35W
- LED Bulb: CREE: XP HI/XPG2
- Color Temp: 5000K
- Amp Draw: 1.88A
- Voltage: 9V-18V
- IP Rating: IP68
- Product Dimensions: W - 6.96 x D - 5.098
GRAVITY LED EXTREME OUTPUT AND EFFICIENCY
The Gravity LED Pro 7 headlight uses KC's newly patented Gravity® Projector Optic (GPO). Utilizing this proprietary projector lens technology along with a GRD LED core, KC engineers were able to deliver a more controlled beam pattern while setting new industry standards in light shape, clarity, and output.
HIGH-PERFORMANCE LED OPTICS
The Gravity LED Pro 7 Headlight features KC's patented Gravity GPO & GRD technology, which is engineered to direct every lumen from the LEDs to the reflector optics.
HIGH/LOW/DRL FUNCTIONS
High/Low beams with DRL functionality come standard in this KC LED projector headlight greatly improving visibility and clarity over factory 07-18 Jeep JK halogen headlights.
DESIGNED FOR DURABILITY
Surrounding our high-performance Pro 7 Headlight is a durable die-cast housing and a hard coated Polycarbonate lens, designed to withstand the harshest climates, terrains, and driving conditions.
